Product information
| brand | TELWIN |
|---|
Technical detail
- SINGLE PHASE MAINS VOLTAGE: 230 V
- MAINS FREQUENCY: 50 / 60 Hz
- MAX NO LOAD VOLTAGE: 96 V
- CURRENT CONTROL RANGE DC: 20 - 220 A
- MAX CURRENT DC EN60974-1: 180 @ 20% A
- CURRENT 35% DC: 135 A
- DC CURRENT: 100 A
- MAX ABSORBED CURRENT: 32 A
- ABSORBED CURRENT AT 60%: 16 A
- MAX ABSORBED POWER: 5 kW
- ABSORBED POWER AT 60%: 2,3 kW
- EFFICIENCY: 84 %
- POWER FACTOR: 0,7
- D. USABLE ELECTRODES IN DC: 1,6 - 4 mm
- STEEL WELDING WIRE DIAMETER: 0,6 - 1 mm
- INOX WELDING WIRE DIAMETER: 0,8 - 1 mm
- ALUMINIUM WELDING WIRE DIAM.: 0,8 - 1,2 mm
- FLUX CORED WELDING WIRE DIAM.: 0,8 - 1,2 mm
- BRAZING WIRE DIAM.: 0,8 - 1 mm
- PROTECTION DEGREE: IP23
- DIMENSIONS: 87 x 53 x 166,5 cm
- WEIGHT: 59 kg
Features
- Multiprocess inverter welding machine (MIG-MAG / FLUX / Brazing / MMA / TIG DC-Lift).
- 220A output for powerful and stable welding.
- Includes 2 MT15 torches, 1 MT25 torch, cable, and earth clamp.
- Ready for immediate use of three torches.
- Automatic torch recognition for easy operation.
- Pulse welding programs for aluminum and galvanized sheet metal.
- Low thermal load (ATC) ideal for thin materials.
- Wave OS operating system with advanced control.
- 55 customizable welding programs.
- USB data saving for traceability and analysis.
- TFT color screen with user-friendly interface.
- Low energy consumption for efficient performance.
