Product information
| brand | TELWIN |
|---|
Technical detail
- SINGLE PHASE MAINS VOLTAGE: 230 V
- MAINS FREQUENCY: 50 / 60 Hz
- CURRENT RANGE: 10 - 40 A
- MAX CUTTING CURRENT EN60974-1: 40 @ 20 % A
- MAX NO LOAD VOLTAGE: 313 V
- MAX ABSORBED CURRENT: 29 A
- MAX ABSORBED POWER: 4 kW
- FUSE: 16 A
- EFFICIENCY: 85 %
- POWER FACTOR: 0,7
- MAX CUTTING THICKNESS: 15 mm
- COMPRESSED AIR CAPACITY: 100 l/min
- COMPRESSED AIR PRESSURE: 4 - 5 bar
- PROTECTION DEGREE: IP23
- DIMENSIONS: 55 x 14,5 x 24 cm
- WEIGHT: 6,48 kg
Features
- Plasma cutting inverter system with compressed air
- Pilot arc start with contact strike for easy cutting
- Includes PH cutting torch
- Cuts all conductive materials up to 15 mm thickness
- Lightweight and compact for easy transport
- Consumables replacement indicator
- Automatic torch cooling for stable performance
- Air pressure display for accurate operation
- Built-in protection: thermostatic, overvoltage, under voltage, and overcurrent
- Energy-efficient inverter technology for low power consumption
