Product information
| brand | TELWIN |
|---|
Technical detail
- THREE PHASE MAINS VOLTAGE: 400 V
- MAINS FREQUENCY: 50 / 60 Hz
- MAX SPOT-WELDING CURRENT: 15000 A
- MAX NO LOAD VOLTAGE: 13 V
- MAX ABSORBED POWER: 68 kW
- RATED POWER X=50%: 10 kW
- FUSE: 32A A
- POWER FACTOR: 0,8
- INVERTER FREQUENCY: 8000 Hz
- MAX WELD.THICK. ON 2 SHEETS: 3 + 3 + 3 mm
- MAX ELECTRODES POWER: 580 daN
- DUTY CYCLE: 2 %
- PROTECTION DEGREE: IP20
- DIMENSIONS: 80 x 52 x 115 cm
- WEIGHT: 100 kg
Features
- Inverter spot welding machine with Wave OS technology.
- TFT color display panel for easy control.
- Liquid-cooled pneumatic clamp for heavy-duty use.
- SMART AUTOSET for automatic material and thickness detection.
- Automatic welding parameter adjustment for precise results.
- POWER GUN technology with integrated power circuits.
- Long 5m lightweight cables for wider working range.
- USB data saving for welding records.
- Spot Welding Data Management for monitoring and analysis.
- Optional Wi-Fi connectivity kit for data transfer.
- Wide range of arms and electrodes available.
