Product information
| brand | TELWIN |
|---|
Technical detail
- SINGLE PHASE MAINS VOLTAGE: 230 V
- MAINS FREQUENCY: 50 / 60 Hz
- MAX NO LOAD VOLTAGE: 52 V
- CURRENT CONTROL RANGE DC: 20 - 220 A
- MAX CURRENT DC EN60974-1: 180 @ 20% A
- CURRENT 35% DC: 135 A
- DC CURRENT: 100 A
- MAX ABSORBED CURRENT: 32 A
- ABSORBED CURRENT AT 60% 18 A
- MAX ABSORBED POWER: 5,0 kW
- ABSORBED POWER AT 60%: 2,2 kW
- EFFICIENCY: 87 %
- POWER FACTOR: 0,7
- D. USABLE ELECTRODES IN DC: 1,6 - 3,2 mm
- STEEL WELDING WIRE DIAMETER: 0,6 - 1 mm
- INOX WELDING WIRE DIAMETER: 0,8 - 1 mm
- ALUMINIUM WELDING WIRE DIAM.: 0,8 - 1 mm
- BRAZING WIRE DIAM.: 0,8 - 1 mm
- PROTECTION DEGREE: IP23
- DIMENSIONS: 82,5 x 36 x 67 cm
- WEIGHT: 21 kg
Features
- Multiprocess inverter welding machine (MIG-MAG / Brazing / MMA / TIG DC-LIFT)
- 220A output for strong and reliable welding performance
- Synergic control panel with easy 3-step parameter adjustment
- Supports wire reels up to 15 kg (Ø 300 mm)
- Built-in protection: thermostatic, overvoltage, undervoltage, and overcurrent
- Generator compatible (230V ±15%) for flexible operation
- MMA welding with rutile electrodes up to 3.2 mm
- Energy-efficient inverter technology for low power consumption
