Product information
| brand | Sagola |
|---|
Technical detail
- Weight without cup: 474.8 g.
- Dimensions without cup: 18.2 x 1.9 x 17.8 cm.
- Air inlet couplings BSP: 1/4” M
- Cup capacity: 650 ml
- Cup: Removable anti-drip system
- Maximum design pressure: 8 bar
- Air inlet pressure max :2 bar
- Maximum recommended application distance GTO EPA: 18 - 20 cm.
- Maximum recommended application distance GTO HVLP: 12 - 15 cm.
- Average paint output flow (nozzle 1.4 mm. 20”) GTO EPA: 179 g/min
- Average paint output flow (nozzle 1.4 mm. 20”) GTO HVLP: 145 g/min
- Average paint output flow (nozzle 1.4 mm. 20”) GTO EVO: 179 g/min
- Air consumption (2 bar inlet) GTO EPA: 250 L/min
- Air consumption (2 bar inlet) GTO HVLP: 360 L/min
- Air consumption (2 bar inlet) GTO EVO: 255 L/min
- Fan size GTO EPA [1.8]: 250 mm.
- Fan size GTO HVLP [1.8]: 250 mm.
- Fan size GTO EVO [1.4]: 280 mm.
- Average sound pressure level: 80 dB
