Product information
| brand | G5 China |
|---|
Technical detail
- Dimensions (Height*Width*Depth) : 1255mm*720mm*435mm (49.4"*28.3"*17.1")
- Net Weight: 89kg/196.2lbs
- Gross Weight: 106kg/233.7lbs
- Packing Size (Height*Width*Depth) 1380mm*730mm*510mm (54.3"*28.7"*20.1")
- Power Requirement: 100-240Vac 50/60HZ
- Power Consumption: 30VA
- Operating Temperature Range: -20°C/-4°F to 70°C/158°F
- Compressed Air Input Range : 87-123PSI/6-8.5bar/600-850kPa
- Compressed Air Input Flow : 250L/min (8.0cfm)
- Nitrogen Purity: 95-99+%
- Nitrogen Output: 58L/min (2.0cfm) @116PSI/8bar/800kPa Absorption pressure
- Maximum Nitrogen Pressure in Tank: 102PSI/7bar/700kPa
- Operating Range: 5-90PSI/0.3-6.2bar/35-620kPa
- Resolution: 1PSI/0.1bar/5kPa
- Units of Measurement: PSI/bar/kPa
